Socket ／ FRR-20 Socket (φ) 2.00 mm pitch　Right angle (1 row/2 rows)
【Resin part】 Material：LCP(Glass encapsulated thermoplastic resin polyester)
  Color：Black
  Thermal deformation temperature：1.80 MPa: 275℃
  Flammability：UL94V-0
【Sleeve】
sleeve挿絵		 Material：CuZn36Pb3(C36000)
Treatment：Pure tin plating
【Contacts】
contacts挿絵		 Material：Beryllium copper(C17200)
Treatment：Gold plating0.75μm
【Specifications】 Current capacity：3A
  Insulation resistance：10000MΩ min (500Vac)
  Contact resistance：10mΩ max
  Operating temperature range：-55℃ to + 125℃
  Withstand voltage：1000Vrms min
  RoHS compliant product
■FRR-21036-00　(1 row)
Drawing Right angle
Stacking quick selection table
MOQ:10pcs
H Number of pins Product code Unit Price($)
3.63 2 FRR-21036-02 0.69
3 FRR-21036-03 0.96
4 FRR-21036-04 1.17
5 FRR-21036-05 1.40
6 FRR-21036-06 1.73
7 FRR-21036-07 2.04
8 FRR-21036-08 2.28
9 FRR-21036-09 2.53
10 FRR-21036-10 2.77
20 FRR-21036-20 5.37
■FRR-22036-00　(2Rows)
Drawing Right angle
Stacking quick selection table
MOQ:10pcs
H Number of pins Product code Unit Price($)
3.63 4 FRR-22036-02 1.27
6 FRR-22036-03 1.91

8

 FRR-22036-04 2.46
10 FRR-22036-05 3.08
12 FRR-22036-06 3.68
14 FRR-22036-07 4.28
16 FRR-22036-08 4.90
18 FRR-22036-09 5.52
20 FRR-22036-10 6.13
40 FRR-22036-20 12.08
●Example of vertical mounting
Example of vertical mounting
●Example of horizontal mounting
Example of vertical mounting
