Spacer for round LEDs( 10 coupled blocks) / LDZ-300C

● 2 types of spacer for round and square type LEDs.
● 3φ and 5φ LEDs can be linked without ineffi cient use of space with 10 piece coupling at 5.08 mm pitch.
● Can be cut easily to desired number at 10 pieces or less (cutting tools unnecessary).
● Vertical/horizontal dual use.
● For LED head diameter of 3φ or 5φ.
● Square type (for 2 legs only), round type (2/3 leg dual use).

Material：PBT (grade #1184G)
Color：Black
Thermal deformation temperature：1.82Mpa:200℃
UL standard：UL94V-0(Material)
RoHS compliant product
Use example
■LDZ-300C
Drawing
For 2 legs
MOQ:50pcs
L Product code Unit Price($)
3 LDZ-303C 0.41
3.5 　LDZ-303.5C 0.41
4 LDZ-304C 0.41
4.5 　LDZ-304.5C 0.41
5 LDZ-305C 0.41
6 LDZ-306C 0.41
7 LDZ-307C 0.41
8 LDZ-308C 0.41
9 LDZ-309C 0.41
10 LDZ-310C 0.48
11 LDZ-311C 0.48
12 LDZ-312C 0.48
13 LDZ-313C 0.48
14 LDZ-314C 0.48
15 LDZ-315C 0.48
