Spacer for round LEDs( 10 coupled blocks) / LDZ-700C

● 2 types of spacer for round and square type LEDs.
● 3φ and 5φ LEDs can be linked without ineffi cient use of space with 10 piece coupling at 5.08 mm pitch.
● Can be cut easily to desired number at 10 pieces or less (cutting tools unnecessary).
● Vertical/horizontal dual use.
● For LED head diameter of 3φ or 5φ.
● Square type (for 2 legs only), round type (2/3 leg dual use).

Material:PBT (grade #1184G)
Color:Black
Thermal deformation temperature:1.82Mpa:200℃
UL standard:UL94V-0(Material)
RoHS compliant product
Use example
■LDZ-700C
Drawing3Φ・5Φ
2,For 3 legs
MOQ:50pcs
L Product code Unit Price($)
3 LDZ-703C 0.44
3.5  LDZ-703.5C 0.44
4 LDZ-704C 0.44
4.5  LDZ-704.5C 0.44
5 LDZ-705C 0.44
6 LDZ-706C 0.44
7 LDZ-707C 0.44
8 LDZ-708C 0.44
9 LDZ-709C 0.44
10 LDZ-710C 0.51
11 LDZ-711C 0.51
12 LDZ-712C 0.51
13 LDZ-713C 0.51
14 LDZ-714C 0.51
15 LDZ-715C 0.51
