PCT Pin header ／ FRR-40 Socket (φ) 2.54 mm pitch　Right angle (1 row/2 rows)
Connection side φ0.47mmPin/Connection side φ0.76mmPin
【Resin part】 Material：PCT(Glass encapsulated thermoplastic resin polyester)
  Color：Black
  Thermal deformation temperature: 1.80 MPa: 255℃
  Flammability：UL94V-0
【Sleeve】
sleeve挿絵		 Material：CuZn36Pb3(C36000)
Treatment：Pure tin plating
【Contacts】
contacts挿絵		 Material：Beryllium copper(C17200)
Treatment：Gold plating0.75μm
【Specifications】 Current capacity：3A
  Insulation resistance：10000MΩ min (500Vac)
  Contact resistance：10mΩ max
  Operating temperature range：-55℃- +125℃
  Withstand voltage：1000Vrms min
  RoHS compliant product

☆=Connection side φ0.47mmPin　*=Connection side φ0.76mmPin

■FRR-41037-00(1 row)
Drawing Connection side φ0.47mmPin
Stacking quick selection table
MOQ:10pcs
H Number of pins Product code Unit Price($)
3.7 2 FRR-41037-02 0.72
3 FRR-41037-03 0.78
4 FRR-41037-04 1.06
5 FRR-41037-05 1.13
6 FRR-41037-06 1.21
7 FRR-41037-07 1.39
8 FRR-41037-08 1.47
9 FRR-41037-09 1.78
10 FRR-41037-10 1.83
20 FRR-41037-20 3.57
■FRR-42037-00(2Rows)　
Drawing Connection side φ0.47mmPin
Stacking quick selection table
MOQ:10pcs
H Number of pins Product code Unit Price($)
3.7 4 FRR-42037-02 1.21
6 FRR-42037-03 1.70
8 FRR-42037-04 2.14
10 FRR-42037-05 2.69
12 FRR-42037-06 3.16
14 FRR-42037-07 3.62
16 FRR-42037-08 4.19
18 FRR-42037-09 4.71
20 FRR-42037-10 5.04
40 FRR-42037-20 9.74
■FRR-41036-00(1 row)　
Drawing Connection side φ0.76mmPin
Stacking quick selection table
MOQ:10pcs
H Number of pins Product code Unit Price($)
3.6 2 FRR-41036-02 0.69
3 FRR-41036-03 0.93
4 FRR-41036-04 1.19
5 FRR-41036-05 1.44
6 FRR-41036-06 1.71
7 FRR-41036-07 1.97
8 FRR-41036-08 2.24
9 FRR-41036-09 2.49
10 FRR-41036-10 2.74
20 FRR-41036-20 5.18
■FRR-41070-00(1 row)　
Drawing Connection side φ0.76mmPin
Stacking quick selection table
MOQ:10pcs
H Number of pins Product code Unit Price($)
7 2 FRR-41070-02 0.69
3 FRR-41070-03 0.93
4 FRR-41070-04 1.19
5 FRR-41070-05 1.44
6 FRR-41070-06 1.71
7 FRR-41070-07 1.97
8 FRR-41070-08 2.24
9 FRR-41070-09 2.49
10 FRR-41070-10 2.74
20 FRR-41070-20 5.18
■FRR-42070-00(2Rows)　
Drawing Connection side φ0.76mmPin
Stacking quick selection table
MOQ:10pcs
H Number of pins Product code Unit Price($)
7 4 FRR-42070-02 1.29
6 FRR-42070-03 1.93
8 FRR-42070-04 2.38
10 FRR-42070-05 2.94
12 FRR-42070-06 3.47
14 FRR-42070-07 4.03
16 FRR-42070-08 4.59
18 FRR-42070-09 5.21
20 FRR-42070-10 5.72
40 FRR-42070-20 11.22
●Example of vertical mounting
Example of vertical mounting
●Example of horizontal mounting
Example of horizontal mounting
